Plasmid DNA Fragments

Plasmid DNA fragments were analyzed using Asahipak GS-710 7G (a column for GFC separation).
GS-710 7G is an old type of GF-710 HQ.


Sample : Plasmid DNA Fragment

Columns      : Shodex Asahipak GS-710 7G (7.5mmID*500mm) x 2
Eluent       : 50mM Tris-HCl buffer(pH7.2) + 300mM NaCl + 2mM EDTA-2Na
Flow rate    : 0.1mL/min
Detector     : UV(260nm)
Column temp. : 30deg-C
